John Deere 7400

2005 John Deere 7400 4WD including John Deere 630B 3 meter gras pick up

John Deere 7400

2005 John Deere 7400 4WD including John Deere 630B 3 meter gras pick up

Price on request

When you enter your E-mail address, we will send you the Dekra report.

Technical specifications

Stock Number 25033-30
Brand John Deere
Model 7400
Series 7000
Engine hours 4740
Road speed (km/h) 40
Drum hours 3341
Attr 2 or 4 wheel drive 4 WD
Engine Brand John Deere
Engine type L6
Engine Power HP 502
Engine Power (KW) 375
Front Tires Brand Michelin
Rear Tires Brand Michelin
Front Tires Size 800/65 r32
Rear Tires Size 540/65 r26
Front Tires profile 75
Rear Tires Profile 45
Emission Level Tier 3

Knife drum 56
Amount of knives installed 28

Kernel processor type Saw tooth

Options

Auto lubrication Yes
Spout extension Yes
Trailer hitch Yes
Autopilot module prepared Yes
LED lights Yes
Sunblinds window(s) Yes
Road registration papers Yes

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Machine documents

Harvester Guard ® Inspection certificate

Image gallery

Load more images >>>

Innovation
Knowledge
Quality
Transparent

AM: Harvester Guard® Inspection Report

V = working | X* = not working, note repair recommendations | n.a. = not applicable

New
- 5
Like New
- 4
Good
- 3
Fair
- 2
Poor
- 1

Levels

Anti-freeze level in °C - 30 °C
Cooling liquid level X*
Engine oil level X*
Hydraulic oil level X*
Left hand front end drive oil level V
Rear axle oil level V
Left hand rear end drive oil level X*
Right hand rear end drive oil level X*
Upper feedrolls gearbox oil level X*
Gearbox oil level V
Brake fluid X*

Knive drum

Knife drum 56
Amount of knives installed 28
Knife condition 23%%
Knife holders V
Knife drum configuration Grass
Shearbar front surface 5
Shearbar rear surface 3
Shearbar active position Rear
Left hand Knife drum bearing X*
Right hand Knife drum bearing V
Knife drum bottom plate 3
Knife drum rear plate 3
Knife drum front cover 3
Knife drum stone cover 3
Knife drum chain coupler V
Sharpening stone 2
Left hand lift cilinder X*
Right hand lift cilinder X*

Kernal processor

Gras chute liner 3
Corn shute liner 2
Kernel Processor rolls 3
Kernel Processor upper roll 3
Kernel Processor lowwer roll 3
Kernel processor type Saw tooth
Kernel Processor drive belt 3
Kernel Processor drive tensioner bearings X*
Kernel Processor drive idler roller X*
Kernel processor belt tensioner rolls X*
Kernel Processor housing 2
Tensioner springs gap adjustment V
Wear plates 2

Feedrolls

Upper front feedroll 2
Upper rear feedroll 3
Metal detector roll 3
Smooth roll 2
Smooth roller chain coupler X*
Smooth roll scraper 3
Upper front feedroller left hand bearing V
Upper rear feedroller left hand bearing X*
Upper rear feedroller right hand bearing X*
Metal detector roll left hand bearing X*
Metal detector roll right hand bearing V
Smooth roll left hand bearing X*
Smooth roll right hand bearing X*
Upper feedroller arm bushing X*
Feeder housing wear plates 1
Upper feedrolls drive shaft V
Upper feedrolls tension springs V
Upper feedrolls arm Bump stops X*
Loc gearbox X*
Gearbox upper feedrolls X*
Metal detector roll drive shaft V

Corn cave

Corn cave liner 3
Corn cave top liner 2
Corn cave door 3

Blower

Blower paddles 75%
Blower liner 3
Blower housing V
Left hand blower bearing V
Right hand blower bearing V

Transition housing

Transition housing 3
Transition liners 3

Spout

Spout turnable wear shims 2
Spout swivel tube 3
Spout complete housing 1
Spout front liner 3
Spout middle liner 4
Spout rear liner 4
Spout side liners 2
Spout extention 3
Spout extention liner 2
Inner Spout deflector 2
Outer Spout deflector 4

Engine

Dry engine V
Waterpump bearings V
Engine belting V
Engine belt tensitioners V
Exhaust system V
Engine mounting V
Airfilters X*
Rotary air screen V
Rotary air screen rollers V
Cleaner cooling package X*
Engine belting idler roller V
Rotary air screen belt tensioner roller V
Rotary air screen belt V
Rotary screen fan drive belt N.A.
Rotary screen fan drive belt tensioner N.A.

Main drive

Main clutch 3
Main drive belt 3
Main belt tensioner bearings X*

Operators station

Front window V
Rear window V
Cab door V
Cab door latch V
Cab right hand window V
Cab roof V
Cab front bottom cover V
Mirrors V
Joystick V
Armrest control panel V
Steering wheel adjustment V
Front window wiper X*
Rear window wiper blade N.A.
Side window wipers blade X*
Cab air filter X*
Seat V

Machine body

Front cover V
Left hand cover X*
Right hand cover X*
Rear cover X*

Functional test

Engine oil pressure low idle cold 4
Engine oil pressure high idle cold 4,8
Engine oil pressure low idle operating temperature 3,8
Engine oil pressure high idle operating temperature 2
Hydrostatic drive neutral X*
Transmission shifting V
4WD working X*
Foot brakes L/R X*
Parking brake X*
Main clutch working V
Autolube X*
Length of cutt adjustment V
Header speed adjustment V
Header height control V
Header Lateral Tilt - if applicable N.A.
Front hydraulics V
Dump valve (high flow hydraulics) N.A.
Spout turning V
Metal detector X*
Spout deflector V
Sharping system V
Shearbar adjustment V
Cutterhead reverser V
Kernel Processor gap adjustment V
Airconditioning cold V
Cab heating V
Electrical functions cabin V
Camera(s) N.A.
Radio V
Road & Working Lights V
Free of error codes X*
